- [WIDE APPLICATION] This multifunctional pneumatic liquid filling machine is suitable for all kinds of liquids, pastes and sauces, such as lipstick, shampoo, perfume, wax products, toothpaste, lotion, honey, butter, cream, milk, coffee, chili sauce and so on. Suitable for any field, this is a very high quality filling machine.
- [EASY TO USE] This manual filling machine is equipped with a 60W pure copper motor with 36 rpm and dual industrial grade heating tubes (0.75kw*2) for even and efficient stirring and heating of raw materials for smooth and efficient filling. The panel designed with temperature control, indicator light, valve heating switch, stirring switch, cavity heating switch and temperature display allows easy and orderly control of different modules for efficient filling.
- [HIGH-QUALITY] Made of heat resistant, high quality 304 stainless steel plate (0.08" thick) that will not react with the material, providing excellent durability while maintaining filling purity. Stainless steel discharge port, controlled by C-type heating tube and ball valve, enables constant temperature heating and manual control of the entire discharge for greater precision.
- [HIGH EFFICIENCY] The heating layer can reach 90℃ with water, and the highest heating temperature can reach 300℃ with heat-conducting oil, which can be adjusted to different heating temperatures according to different materials, making it more convenient to use. The excellent heating and stirring function can easily achieve the efficient filling of 20-45 bottles per minute, which will greatly save time and energy to meet the commercial demand.
- [QUALITY ASSURANCE] We have strict quality control system, our products are put into the market after rigorous testing. Please allow the slight color difference caused by the shooting light and 1-3cm error due to manual measurement, and make sure you do not mind before you order.
Key Features
High-quality Material: Corrosion and heat-resistant high-quality 304 stainless steel plate (thickness 0.08 inch) will not react with the material, ensuring the purity of filling while providing excellent durability. Professional automatic argon arc welding process to create seamless and dense welded joints.
Uniform Stirring & Heating: Powerful pure copper motor (max. speed 36rpm, power 60 watts), T-shaped paddle, and double industrial grade heating tubes (0.75kw*2) provide uniform and efficient stirring and heating for the material, which makes the filling more smooth and efficient.
Specification
Model: YK-15L
Application: Liquid, Paste
Material: 304Stainless Steel, Copper
Process: Automatic Argon Arc Welding. Polishing
Color: Silver
Assembly Required: Yes
Filling Mode: Manual
Power Sources: Electric Corded
Voltage: 110V 60HZ
Plug: US Standard
Capacity: 15L/4gal
Heating Power: 1.5kw(2*0.75kw)
Stirring Power: 60w
Stirring Motor Max. Speed: 36rpm
Power Supply: 2.1kw
Outlet Heating Power: 120w
Certificate: CE
Filling Accuracy: ±1%(Specific Accuracy is Controlled Manually)
Adjustable Temperature: 0-300℃/32-572℉
Filling Speed: 20-45 Bottle/min(Depends on Actual Personal Degree of Operation Proficiency)
Gross Weight: 22kg/48.5lbs
Net Weight: 20kg/44lbs
Package Size: 55*52*40cm/21.7*20.5*15.7in
Product Size: 53*39*70cm/20.87*15.35*27.56in
Bucket Wall Thickness: 2mm/0.08in
Package Included
1*Lipstick-filling Machine
1*Stirrer
4*Support Pillars
1*English User Manual
All Accessories Needed for Use
Notes
1. The water filling port is also used to discharge steam, please do not block it.
2. Please clean the drum before use.
